Drier Cooler — 50-500 TPD
Meal coolers bring extracted meal down from desolventiser temperature and dry it at the same time, on counter-current or cross-flow air. That stops thermal degradation, removes the fire risk in storage, and leaves the meal safe to handle.
Every Drier Cooler is built to your plant’s throughput at our Pithampur works in India and exported to solvent extraction plants and oil mills abroad — 22+ countries across five continents to date. Capacity, drive rating, your supply voltage and frequency, and the interfaces to the machines either side of it are all settled before fabrication starts.
- Capacity Range
- 50-500 TPD
- Temperature Reduction
- 100-110°C → ~40°C
- Construction
- Stainless steel
- Built and shipped
- Made at Pithampur, India — exported worldwide, FOB Indian port
Models & Configurations
- Counter-current air system: Air flows against the meal bed for maximum heat exchange
- Cross-flow air system: Air crosses the meal bed for gentler treatment
- Stainless steel construction: For continuous hot, moist duty
Specifications
Key Features
- Integrated rotary valves for material handling and airlock
- Uniform cooling prevents hot spots
- Energy-efficient design minimizes operating costs
Applications
- Post-extraction meal cooling
- Soybean and sunflower meal processing
- Rapeseed and cottonseed meal operations
Export Supply and Shipping
- Shipping: Containerised in sub-assemblies where the machine’s envelope allows, otherwise flat rack or break bulk; FOB Nhava Sheva or Mundra, or CIF your port.
- Electrics to destination: Motors, gearboxes and panel built for your supply — 380, 400, 415 or 440 V at 50 or 60 Hz — and CE marked where required.
- Packing: Product-contact surfaces cleaned and wrapped, machined faces preserved against sea air, and everything crated on ISPM-15 heat-treated timber.
- Erection support: General arrangement, foundation and utility drawings at order; a commissioning engineer can be deputed to run the machine in on your own feedstock.
- Documents and payment: Commercial invoice, packing list, certificate of origin, material test certificates and bill of lading; quoted in US dollars.
Frequently Asked Questions
What capacity range do your drier coolers cover?
Lines from 50 to 500 TPD, taking meal from 100-110°C down to around 40°C at a final moisture of 10-12%.
Why must meal be dried and cooled before storage?
Hot, moist meal degrades in storage and can self-heat. Bringing it to around 40°C and 10-12% moisture makes it safe to bag, store, and transport. Counter-current and cross-flow air configurations are available.
Is the drier cooler customised to my requirement?
Yes. Every machine we build is custom-engineered — capacity, dimensions, and configuration are matched to your line. Send your requirement via the enquiry form or call +91 91091 02280 for a firm quote.
Can you export the Drier Cooler and support the erection at our plant?
Yes. We have supplied oil seed processing equipment to buyers in 22+ countries across five continents. The machine is containerised in sub-assemblies where its envelope allows, and a commissioning engineer can be deputed to erect it and run it in on your own feedstock.
